100 MHz Socoje Digital Oscilloscope, 4 Channels, 1 GSa/s 1 set
from
$1,318.41
Ex Tax: $1,318.41
- Stock: In Stock
- Model: SCJ009654
- SKU: SCJ009654
- UPC: 315972718205
Products Sold: 0
Product Views: 349
Ask a Question About This Product
- Description
100 MHz Socoje Digital Oscilloscope, 4 Channels, 1 GSa/s 1 set
Brief
SOCOJE digital oscilloscope offers sample rate of up to 1 Gsa/s, bandwidth of 100 MHz, 4 channels, a waveform capture rate of up to 45,000 wfms/s and a large LCD screen that can show any measured alternating current.
Description
4-channel digital oscilloscope with 100 MHz bandwidth, 1 GSa/s sampling rate. The oscilloscope with USB design, which can improve work efficiency, and convenient for storage.
Specification
| Model | SCJ009654 |
| Bandwidth | 300 MHz |
| Channel | 2+ external trigger |
| Sample rate | 2.5 GSa/s |
| Acquisition model | Sample, Peak detect |
| Record length | 10M |
| Display | 8 inch LCD |
| Waveform refresh rate | 10000 wfrms/s |
| Input coupling | DC, AC, Ground |
| Probe attenuation | 1X, 10X, 100X, 1000X |
| Input Impedance | 1MΩ ± 2%, in parallel with 15pF ± 5pF |
| Max. input voltage | 400V (DC+AC, PK - PK) |
| Bandwidth limit(typical) | 20MHz / Full bandwidth |
| Sampling rate range | 1ns/div ~ 100s/div,step by 1-2-5 |
| Vertical Resolution | 8 bits |
| Sensitivity Resolution | 2mV/div~10V/div |
| Low Frequency（-3db） | ≥10 Hz (at input, AC coupling) |
| Rise time (at input, Typical) | ≤5.8ns |
| Trigger type | Edge |
| Trigger model | Auto, Normal, single |
| Trigger level range | ±6 div from the screen center |
| Automatic measurement | Vpp, Vavg, Vrms, Frequency, Period, Vmax, Vmin, Vtop, Vbase, Vamp, Overshoot, Preshoot, Rise Time, Fall Time, +Width, -Width, +Duty, -Duty, DelayA→B , DelayA→B |
| Cursor measurement | ΔV, ΔT, ΔT&ΔV between cursors,auto cursor |
| Dimension | 340*155*70mm |
| Weight | 1.8kg |
Accessories
- Power cable
- USB cable
- Probe
- Probe Adjust
- Quick Guide
Application
Tips: What is the difference between a digital oscilloscope and an analog oscilloscope?
The main difference between analog and digital oscilloscopes is that in digital Oscilloscopes, the analog signal is captured and converted into a digital signal using an analog to digital converter. The advantage of using digital oscilloscopes is that you can easily store digital data in digital memory.
