Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved

Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved
Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved
Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved
Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved
Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved
Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved
Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved
Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved
Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved
Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved
Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved
Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved
Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved
Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved
Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved
Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved
Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved
0 reviews - Write a review
from
$450.00
Ex Tax: $450.00
  • Stock: In Stock
  • Model: SCJ004184
  • SKU: SCJ004184
Products Sold: 0
Product Views: 845
Add to Cart
Buy Now Ask a question
Add to Wish List Compare this Product
Add to Cart
Buy Now
  • Specifications
attribute-list
MaterialBoron Silicate Glass
TypeKD1650
Wave Length10.6μm
Beam Diameter2.5 mm
Max Power150 W
Rated Power150 W
Length(±50 mm)1650 mm/64.96 inch
Outer diameter(±2 mm)80 mm/3.15 inch
Optimal operating current12-25 mA
Coolingwater cooling 15-30℃
GROSS WEIGHT7.9 lbs
Working Voltage28 KV
  • Description
About this product
1.Model: KD1650;Length:1650 mm;Diameter:80 mm;Power Range:130W-150W;Lifespan: 10000 hours.
2.The actual power is 150W, but you will receive a tube marked 130W. Please don't mind!!!
3.HIGH TEMPERATURE RESISTANCE,This laser tube is made of the boron silicate glass that is also applied on the solar tubes. It is resistant to high temperature and high pressure.
4.TEMOO MODE,The CO2 laser tube adopts the TEMPOO mode, which is characterized by high spot concentration, high energy density as well as good and stable spot. At the same time, the use of output mirrors further enhances the mode.
5.SPECIAL COATING TECHNOLOGY,The inside of the discharge tube uses the special coating technology. The coating is a reduction catalyst mixed with materials such as rare earth and gold.
6.VARIOUS APPLICATION,Professional 150W laser, one of the spare parts of CO2 laser engraving machine, widely used in engraving and cutting acrylic, cloth, leather, bamboo, wood and other materials.

Package Content: 1×Laser Tube

Packing size : 74.8×11.8×11.8 inch

Gross weight: 3.6 kg/7.9 lbs

FDA certificate is available

Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved

JOY Laser is a professional manufacturer of CO2 laser tubes.Professional glass laser tube, mainly used in laser engraving machine, laser marking machine and laser cutting machine. It is a spare part for laser machines that can engrave and cut acrylic, cloth, leather, bamboo, wood and other materials. Our CO2 laser tube  adopts the uses German Schoot discharge tube and special coating technology to improve the performance of the laser tube. It is definitely your best choice.


KD1650: 150W CO2 Laser Tube

Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved

Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved

Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved

Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved


Actual 150W CO2 Laser Tube Length 1650mm Dia 80mm, Wires Preconnected with Coating, for Laser Engraver Cutter Laser Engraving Machine FDA Approved
