DIY Laser Cutter Built-In CAMERA Scan Photos for Cutting Engraving 40W

DIY Laser Cutter Built-In CAMERA Scan Photos for Cutting Engraving 40W
DIY Laser Cutter Built-In CAMERA Scan Photos for Cutting Engraving 40W
DIY Laser Cutter Built-In CAMERA Scan Photos for Cutting Engraving 40W
DIY Laser Cutter Built-In CAMERA Scan Photos for Cutting Engraving 40W
DIY Laser Cutter Built-In CAMERA Scan Photos for Cutting Engraving 40W
DIY Laser Cutter Built-In CAMERA Scan Photos for Cutting Engraving 40W
DIY Laser Cutter Built-In CAMERA Scan Photos for Cutting Engraving 40W
DIY Laser Cutter Built-In CAMERA Scan Photos for Cutting Engraving 40W
DIY Laser Cutter Built-In CAMERA Scan Photos for Cutting Engraving 40W
DIY Laser Cutter Built-In CAMERA Scan Photos for Cutting Engraving 40W
DIY Laser Cutter Built-In CAMERA Scan Photos for Cutting Engraving 40W
DIY Laser Cutter Built-In CAMERA Scan Photos for Cutting Engraving 40W
DIY Laser Cutter Built-In CAMERA Scan Photos for Cutting Engraving 40W
DIY Laser Cutter Built-In CAMERA Scan Photos for Cutting Engraving 40W
DIY Laser Cutter Built-In CAMERA Scan Photos for Cutting Engraving 40W
DIY Laser Cutter Built-In CAMERA Scan Photos for Cutting Engraving 40W
DIY Laser Cutter Built-In CAMERA Scan Photos for Cutting Engraving 40W
from
$2,600.00
Ex Tax: $2,600.00
  • Stock: In Stock
  • Model: SCJ004087
  • SKU: SCJ004087
Products Sold: 0
Product Views: 167
  • Specifications
attribute-list
VoltageAC 110 V ± 10%, 1 phase, 60 Hz
Laser Power40W
Power400W
Working Area12-19/32" x 7-7/8" (320 x 200 mm)
Laser TypeCO2 Sealed Glass 10.64 um
WorktableHoneycomb
Control systemRuida / Image Capture System
Lifting WorktableYes (Electric)
Motor & DriverStep motor
Worktable Lift Depth2-1/2" / 70mm
Max. Engraver Speed35-7/16"/s (900 mm/s)
Cutting Thickness3/32" (2.5 mm) on acrylic
Locating Precision± 0.01 mm
Min. Character Size1 mm × 1 mm
Focus ModeDouble Red Light Focusing
Operating Temperature41℉ - 122 ℉ (5 ℃- 50 ℃)
Data Transfer InterfaceUSB 2.0
Max. CUTTING SPEED12"/s (300 mm/s)
System EnvironmentIOS / Windows
Max. Current8A
Design softwareCore draw, Auto cad (compatible), Photoshop
Graphic Format SupportedPLT, DXF, BMP, AI………. (direct);
Graphic Format SupportedJPG, GIF, PGN, TIF…….. (conversion)
Life time of laser tube1000-1500 hours
Certificate:CE, FDA
Cooling ModeWater Cooling & Protection System
Water PumpYes
Air PumpYes
  • Description
About this product

Perfectly designed desktop laser, 6 items protections and friendly software, RM320 laser Suitable for any home, school, office and hobbies.

1. Working area: 12-19/32" x 7-7/8" (320 x 200 mm), (Camera capture 200 x 110mm)

2. Worktable lift depth Z: 2-1/2"

3. Laser tube power 40W. Power Supply: AC 110V, 60 Hz.

4. Support Image capture, Hand-draw & Picture available.

5. CO2 laser suitable for wood, leather, acrylic, fabric, cardboard, anode metal,glass, marble, and much more non-metal materials.

6. Double control software: RD work -Windows system LIGHTBURN- Windows & IOS (Paid)

7. Certification: FDA and CE Certified.

40w industrial laser is Satisfy most materials engraving and cutting works.Use the built-in HD 200W 1080P camera to preview the work area and the work piece on your laptop DIY Laser Cutter Built-In CAMERA Scan Photos for Cutting Engraving 40W . Place your design exactly where you want and get exactly what you expect.

  Just use a pen, On board camera will scan your drawing and turn it into a digital file you can print. No matter your skill level, it’s easy to bring your designs to life.

Print where you want

Easy find the focus on different thickness of the material, enabling laser to cut deeper in multiple passes. Fit for 0~70mm object, up and down worktable by step motor, easy and smart.

The closed-loop water cooling & air pump system circulates water /air through out the machine, keeping the components at the proper temperature at all times.

1. Small floor space of just six letter-sized sheets of papers. A little body makes a big difference

2. Use it is fully enclosed, and it automatically pauses if the cover opened during work

3. Key Switch insure only you are her Master ; Emergency button can shut down the machine immediately when an emergency occurs.

4. Built-in sensor, Inside temperature machine over 50℃, laser stop work.

5. Dark color Tempered glass is better to prevent laser out and nonflammable. LED light Provide adequate lighting

She uses a laser that is smaller than the width of a human hair and engraves with 0.05mm layer depth. The 1,000 DPI resolution will amaze you.

Users can shape, cut, and engrave on an enormous range of materials including wood, leather, acrylic, fabric, cardboard, anode metal,glass, marble , and much more non-metal materials.
