High Speed Mechanical Roll Feeder Continuous Pressing Sheet Coil Feeding Machine
from
$800.00
Ex Tax: $800.00
5 or more $500.00
- Stock: In Stock
- Model: SCJ006757
- SKU: SCJ006757
Products Sold: 0
Product Views: 92
Ask a Question About This Product
- Description
Product Description
Specifications
| Model | Strip Width (mm) | Stroke.Max(mm) | Strip Thickness (mm) | Material Line Height (mm) |
| LH-105NS | 100 | 50 | 0-1.6 | 55-100 |
| LH-205NS | 200 | 50 | 0-1.6 | 55-100 |
| LH-255NS | 250 | 50 | 0-1.6 | 55-100 |
| LH-305NS | 300 | 50 | 0-1.6 | 55-100 |
| LH-355NS | 350 | 50 | 0-1.6 | 55-100 |
| LH-405NS | 400 | 50 | 0-1.6 | 55-100 |
| LH-455NS | 450 | 50 | 0-1.6 | 55-100 |
Advantages
1. Continuity: continuous processing for multiple engineering
2. High speed: up to 600 times per minute
3. Universality: regardless of the width and thickness of the material, just adjust the feeder to fit the mold can be used.
4. Simple and practical construction.
5. Low failure rate and easy maintenance.
Form:
Single type: suitable for coil (thickness of 0.15mm or more) single product or continuous punching products.
Double: suitable for coil(thickness 0.15mm or less) short-foot material, single-product continuous punching products.
Feeding accuracy:
Depending on the number of swings and the length of the feed varies (generally its accuracy is 0.03m), if the end of the road positioning, but also can get 0.01mm accuracy.
