New type pneumatic strip feeder for press machine

Pneumatic Feeder

We are the leading the manufacturer and supplier of all type of Pneumatic Feeder such as Air Feeder, NC Servo Roll Feeder, Mechanical Gripper Feeder, New Gripper Series, CAM Feeder, Industrial Pneumatic Feeder, Heavy Duty Pneumatic Feeder, Gear Change Feeder, Gripper Feeder, High Precision Feeder, Nc Servo Feeder, Servo Roll Feeder, Push And Pull Feeder, Band Feeders, Coil Feeder, Mechanical Plunger Actuated Feeder, Zig Zag Feeders, Nc Servo Zig Zag Feeder, Mechanical Roll Feeder, Die Feeder, Roll Feeder, Zig Zag Feeders, Mechanical Plunger Actuated Feeder, Feeders For Power Press, Feeding Machine, Roll Feeder, Die Feeder, Coil Feeder.

-Air Feeder

We have developed the Air feeder Series by installing a special valve that increases the feeding speed. This Air Feeder Series is specially designed for the high production of small parts, especially when long feed strokes are needed.

Versatile
Coil stock can be fed in any direction or angle at any time during the machine cycle. A single feed can push or pull through long or short progressions.

A variety of stock widths and thicknesses can be fed at different speeds and feed lengths. Two or more strips can be simultaneously fed by the same feed.

How To Select a Feeder?
Max. width of your strip in coil form ...mm
Max. stroke length of your feeding ...mm
Max. Min thickness of your strip ...mm
Max. Strokes per minute of press...

Specification:

·Main process

11. The central hole of the main structure is by grinding firstly then electroplating , so as to better ensure its roundness and straightness, which thus enable the core shaft to run smoothly.

12. After processed, the main structure goes through anti-corrosive treatment, and then it is cleaned through ultrasonic wave before assembled so as to guarantee trouble-free when processing leftover materials.

13. The guiding rail is processed through hard chrome plating finish after going high tensile steel heating process. The connection between mobile part and guiding rail goes through accurate grinding so as to make machine moving and its motion flexible and stable.

·Fittings

11. Replaceable directional valve adopts large rounded corner structure,the inner hole is polished by mirror, which greatly improves the feeding speed of feeder and the service life of the sealing ring.

12. Adopting two sets of pneumatic buffers,it can automatically absorb the inertial impact in the process of using the air feeder, effectively reducing the vibration and noise.

13. All screws are installed with high strength press oxygen adhesive , so that they will not be loosened by the shock o of long time use, and can achieve a good sealing effect.

·E type solenoid valve standard model

Suitable for short stroke of press machine, or too long feeding length.

·R type solenoid valve standard model

For high precision feeding, use electromagnetism valve to slack fixed clamp to correct error.

·Left and right zigzag style

Suitable for various forms of parts processing, can save more than 1/2 of the material. The support adopts direct bearing, cooperates with the circular rod slide, no noise, high wear resistance, light load, rapid displacement, and shorten the feeding time. Choose feeding time by electronic control. Simple operation, easy maintenance, high accuracy.
