- Stock: In Stock
- Model: SCJ004156
- SKU: SCJ004156
Ask a Question About This Product
- Description
1. Laser Power: Fiber Laser 30W
2. Software: BJJCZ EZcad
3. Marking Area: 5.9" x 5.9" (150 mm x 150 mm)
4. Certification: FDA Certified
5. Power Supply: AC 110 V ± 10%, 60 Hz
6. System Environment: Windows XP/2000/7/8/10
7. 8G USB flash disk(user manual and training videos)
Packing list:
Items | Specifications | Quantity |
Laser marking machine | ST-F30 | 1 |
Control card | BJJCZ | 1 |
Software program | EZcad | 1 |
User manual & training videos | USB flash disk | 1 |
Power cable | 110V power supply | 1 |
USB cable | USB2.0 | 1 |
Pedal switch | 1.5 meters | 1 |
Alignment bars | Alloy aluminum | 2 |
Alignment screws | Stainless steel | 4 |
Ruler | Stainless steel | 1 |
Hex key wrench | Stainless steel | 1 |
Laser safety goggle | 1064nm laser only | 1 |
Packaging information:
Machine dimension(approximately) | 28.7" L × 14.9" W × 25.9" H (730 mm x 380 mm x 660 mm) |
Machine net weight | 110 lbs (50 kg) |
Packaging method | free-fumigation wooden box |
Package dimension | 30.7" L × 18.9" W × 29.9" H (780 mm x 480 mm x 760 mm) |
Package weight | 125.66 lbs (57 kg) |
Note:
1. It does not include computer. You can use your own laptop or desktop computer.
Machine come with USB flash disk, which has the installation software, user manual andtraining videos. You can install the software on your computer.
2. It does not include rotary clamp. It includes only the port/interface for rotary clamp for future use.
Applicable materials:
1. All metal materials: gold, silver, titanium, copper, alloy, aluminum, steel, stainless steel, carbon steel, zinc and etc.
2. Some non-metals: hard plastic, ABS, PVC, Nylon, PES, Makrolon.
Features:
1. It has integrated design, compact size, and with small volume, light weight, portable, easy to carry and transport.
2. Laser marking is a laser processing way to leave marks on an object.
3. Original EZcad controller, USB interface, swift and stable transmission, easy software operation, strong functions.
4. Red light preview, you can preview the contour of the contents printed in advance on the workpiece.
5. The fiber laser beam comes out from the fiber device directly, no need to adjust the laser optical path.
6. Strong Compatibility: PLT, BMP, DXF, JPG, TIF, AI and other format files that output from CorelDraw, AutoCAD, Photoshop etc.
7. Low power consumption: the gross power of the whole machine is <800W.
8. The technique does not involve the use of inks, nor does it involve tool bits which contact the engraving surface and wear out, giving it an advantage over alternative engraving or marking technologies where inks or bit heads have to be replacedregularly.
