- Stock: In Stock
- Model: SCJ004155
- SKU: SCJ004155
Ask a Question About This Product
- Description
1. Laser Power: Fiber Laser 30W
2. Software: EZ Cad
3. Marking Area: 5.9" ×5.9" (150 mm × 150 mm)
4. Certification: FDA Certified
5. Power Supply: AC 110 V ± 10%, 60 Hz
6. High efficiency, low energy consumption and cost saving.
Equipment features:
Different from the traditional solid-state laser using crystal rod as the laser medium, the medium of fiber laser is a long Yb doped double clad fiber, which is pumped by high-power multimode laser diode.
Characteristics of hl-mf series fiber laser marking machine.
1. Excellent beam quality, suitable for precise and fine marking.
2. The beam quality of MF Series fiber laser marking machine is much better than that of traditional flash lamp pumped and semiconductor pumped solid-state laser marking machines. It is a fundamental mode (TEM00) output, and the divergence angle is 1 / 4 of that of semiconductor pumped laser. It is especially suitable for high precision and fine marking.
3. Small size, easy to carry, portable.
The weight and floor area of MF Series fiber laser marking machine are 1 / 10 and 1 / 4 of that of flash pumped solid-state laser marking machine respectively, which saves space and is easy to handle. It can adapt to the requirements of frequent change of processing place and realize the portability of products.
4. The laser output power is stable and the equipment reliability is high.
The energy fluctuation is less than 2% to ensure the stability of laser marking quality; the average trouble free time can be more than 100000 hours, which is 200 times and 15 times of flash lamp pumped and semiconductor pumped solid-state laser marking machines respectively.
5. High efficiency, low energy consumption and cost saving.
With high efficiency of electro-optic conversion, the equipment power is only 200 ~ 500W, and the daily average power consumption is 10 degrees, which is 1 / 10 of the flash lamp pumped solid-state laser marking machine. Long term use can save a lot of energy consumption for users.
6. The operating software with independent intellectual property rights is easy to operate and powerful.
It can mark vector graphics, text, bar code, two-dimensional code, etc., and can upgrade to realize online marking. It can automatically mark date, shift, batch number and serial number. It supports file formats such as PLT, PCX, DXF and BMP, and directly uses SHX and TTF font library.
