Socoje Tools B290VG 11 inch x 28 inch High Precision Variable Speed Metal Lathe - Metal Lathes
from
$2,430.00
Ex Tax: $2,430.00
- Stock: In Stock
- Model: SCJ004449
- SKU: SCJ004449
Products Sold: 0
Product Views: 90
Ask a Question About This Product
- Description
About this product
11" x 28" High Precision Variable Speed Metal Lathe - Metal Lathes | B290VG
11" x 28" High Precision Variable Speed Metal Lathe - Metal Lathes | B290VG
1.5" spindle bore? Check. Variable speed dial with read out? Check. Tapered roller bearings? Check. Power cross feed? Check.
The B290VG metal lathe is the perfect lathe equipped with a large capacity bore, variable speed and tight tolerances all wrapped into a compact tool. This 11" x 28" precision metal lathe is very high quality, and produces very solid work.
The best feature about this B290VG is the capacity compared with its size. Large and in charge, but will not take up more room than necessary.
We at Socoje Tools love this lathe for all the right reasons, and so do our customers!
Check out all the positive reviews on the B290VG Precision 11" x 28" Metal Lathe.
FEATURES:
- A. Most popular, widely useful variable speed lathe.
- B. V-way bed is hardened and precision ground.
- C. Spindle is supported by precision tapered roller bearing.
- D. MT4 spindle hole gets more capacity.
- E. High precision chuck.
- F. T-slotted cross slide.
- G. Power longitudinal feed allows threading.
- H. Adjustable gids for slidedways.
- I. Top design of gearbox gets more function.
- J. Right and left hand threads cutting is available.
- K. Tailstock can be off set for turning tapers.
- L. Equipped with high quality belt and control board.
- M. Tolerance test certificate, test chart included.
SPECIFICATIONS:
- 1. Distance between centers: 27.5".
- 2. Swing over bed: 11".
- 3. Width of bed: 7".
- 4. Swing over cross slide: 6 1/2".
- 5. Taper of spindle bore: MT5.
- 6. Spindle bore: 1 1/2".
- 7. Number of spindle speeds: variable speed.
- 8. Range of spindle speeds: 50-2000 rpm.
- 9. Range of longitudinal feeds: 0.07-0.20mm/0.0025"-0.012"/r.
- 10. Range of cross feeds: 0.0015"-0.0056"/r.
- 11. Range of inch threads: 8-56TPI, 21 threads
- 12. Range of metric threads: 0.4-3.5mm.
- 13. Taper slide travel: 1.97".
- 14. Tailstock quill travel: 3.1".
- 15. Taper of tailstock quill: MT3.
- 16. Motor: 1.3 horse power.
- 17. 110v Only
- 18. Packing size: 55.1"x 26.7"x 27.5".
- 19. Net weight: 484 LBS.
