- Stock: In Stock
- Model: SCJ004417
- SKU: SCJ004417
Ask a Question About This Product
- Description
3-axis position indicator
3-jaw chuck (10" diam.)
4-jaw face plate chuck (12" diam.)
Face plate (13" diam.)
Quick change tool holder head,
KNUTH is your complete source for finding the perfect CNC machine, milling machine, lathe, drill press, or cutting machine. The KSS 25V has a rigid column drill press with large work tables that are used in the metalworking industries.
- Cost-effective, lasting value
- Practically arranged control panel with ergonomic layout of selection levers
- Mount: Camlock D1-6
- Wide bed, ground and hardened
- Offset tailstock for taper turning
- Large number of thread leads
- Removable gap bridge for machining of large diameter
- Stop spindle with adjustable travel stops
3-axis position indicator
- Resulting in valuable time savings
- For increased productivity
- Easy to read display
- Operator-specific features
- Convenient keyboard layout
- Resolution: 0.0004 / 0.0002"
- Default coordinates
- Axis position is maintained when display is turned off
- Hole circle pattern calculation
- Calculator function
- Storage for 10 tools
- Radius / diameter toggle
- Mm/inch conversion
- Easy expansion and maintenance-free operation
- Display for top (Z0) and box way slide (Z1) both separate and in differential / cumulative mode for lathes
| Working area | |
| Workpiece length (max.) | 59 in |
| Turning diameter over bed | 18 in |
| Turning diameter over support | 9 in |
| Turning diameter over gap bridge | 27 in |
| Gap bridge length | 6 in |
| Bed width | 12 in |
| Swing range of top slide | ±52 deg |
| Travel Z1-axis | 5 in |
| Travels | |
| Travel X-axis | 11 in |
| Headstock | |
| Spindle speed | (12) 25 - 2000 rpm |
| Spindle bore | 2 in |
| Spindle mount | Camlock D1-6 |
| Spindle taper | MT 6 |
| Feed | |
| Feed X-axis | 0 - 0.03 in/R |
| Feed Z-axis | 0 - 0.07 in/R |
| Tapping | |
| Tapping, diametric | (50) 4-112 DP |
| Tapping, module | (39) 0 - 0.28 in |
| Tapping, whithworth | (60) 2-112 TPI |
| Tailstock | |
| Tailstock quill diameter | 2 in |
| Tailstock taper | MK 4 |
| Tailstock quill stroke | 5 in |
| Tailstock traverse adjustment | ± 13 mm |
| Drive capacity | |
| Motor rating main drive | 7.4 Hp |
| Measures and weights | |
| Overall dimensions (length x width x height) | 108.27 x 42.52 x 52.76 in |
| Weight | 4334 lbs |
3-axis position indicator, 3-jaw chuck (10" diam.), 4-jaw face plate chuck (12" diam.), face plate (13" diam.), quick change tool holder head, quick change tool holder, coolant system, steady and follow rest, stop spindle, includes fixed splash guard (wall), chuck guard, foot brake pedal, LED work lamp, reducing sleeve, dead center, thread gauge, operating tools, operator manual
