Vertical Turret Mills 10 inch x 50 inch Multiple Speed Drill Mill Machine DRO
from
$6,575.00
Ex Tax: $6,575.00
- Stock: In Stock
- Model: SCJ004483
- SKU: SCJ004483
Products Sold: 0
Product Views: 155
Ask a Question About This Product
- Specifications
attribute-list | |
Model | HT-4H002 |
Max. Drilling Capacity (Steel) | 1-1/4" |
Max. Drilling Capacity (lron) | 1-1/2" |
Table size: | 10" × 50" |
X/Y-Axis Travel per Handwheel Revolution: | 0.2" |
Amps | 10A |
Max. End Milling Capacity | 1" |
Spindle Taper | R8 |
Max. Face Milling Capacity | 3" |
Longitudinal Table Travel (X-Axis) | 29-15/16 |
Cross Table Travel (Y-Axis) | 15-3/4" |
Knee Table Travel (Z-Axis) | 15-3/4" |
Number of Spindle Speeds | 16 |
Max. Distance Spindle to Table | 18-7/8" |
Ram Travel | 15-3/4" |
Max. Distance Spindle to Column | 21-27/32" |
Spindle travel: | 5" |
Head Swivel (Left / Right) | 90° |
Head Tilt (Front / Back) | 45° |
Packing size (L x W x H) | 64-5/32" x 61" x 86-5/8" |
Turret or Column Swivel | 360° |
Power Requirement | Three-phase 220V 60 Hz |
Spindle Speed | 80 - 5440 RPM |
Quill Auto. Feed | 0.0015, 0.003, 0.006 in./rev. |
Shipping Weight | 2668.1 lbs |
T-slots: | 3, @ 2½ centers, 5/8" wide |
Z-Axis Travel per Handwheel Revolution | 0.1" |
Net weight | 2469.6 lbs |
Horse Power | 3 HP |
- Description
About this product
1. Table size: 10" × 50"
2. 3-Axis DRO
3. Coolant recycling system
4. R8 spindle
5. Automatic downward feed
6. Multiple speeds of belt driven
7. Longitudinal power feed
8. Three-phase 220V 60Hz
Structure:
1. 3-Axis DRO.
2. Forward and reverse spindle switch
3. High or low speed adjustable.
4. See-through chip guard with safety switch
5. Coolant recycling system, motor built-in design
6. Catch tray allows for coolant system upgrade
7. LED lights
8. Chrome-plated handle increases the feel of the handle.
9. Add lubricating oil with hand.
10. Hardened table surface with T-slot.
Function:
1. Automatic downward feed.
2. Longitudinal power feed.
3. This head can be automatically stopped by micro-adjustments.
4. Coolant recycling system.
5. Precision quill feed.
6. Longitudinal limit switch protects the work table, avoid exceeding the range of processing.
7. Protective cover, with automatic power off function.
Advantage:
Ⅰ: See-through chip guard with safety switch, power-off protection, avoid injury during processing.
Ⅱ: Chrome-plated handle and Fine-tuning scale
Ⅲ: Cooling circulation pump, hidden design, not easy to corrosion
