Float switch magnetic sensor water level sensor level and pvdf float switch

1.Acid and alkali resistant materials: Stainless steel 304/316
Other material : PP,PVDF, NYLON, NBR etc..
2.Stainless steel SUS304, SUS316, max working temp.350℃, max proof pressure 60kg/cm2
3.Stainless steel switch body length can reach 120mm~400mm or as your requirements , the length can be adjusted according to your
water
tank, switch body is durability.
4.Multiple wires: electrical wire or cable wire, PVC, XLPE, PTFE materials.
5.Multiple installations, dimensions, from M8~M16, 1/8" ~ 1/2",PF/PT/BSP etc..

Buy Now

Technical Parameters

Product Name: Float Switch Sensor

Material: Stainless steel 304/316

Size: Rod length :220MM , Cable length : as your requirements , Terminal /connector : as your requirements

warranty: 1 year

Operating Temperature: -30~+180℃

Max. Voltage: 220VDC

Max. Current: 1.5A

Contact Form: Normally Open, Normally Closed, Change Over

Cable length: 350mm or customize

Description

Float switch is composed of reed switch and float. The float will activate the reed switch soon as the rising or falling fluid reaches the defined fluid level, a contact is closed or opened. This instructs a magnet located in the float to activate one or more reed switches in the riser of the float switch.

Applications :Float level switches are widely used in electronic, electrical, chemical, water treatment, drainage and other industry of level control and alarm.
