G1/2 Flow Sensors Magnetic 1-30L/min Hall Effect Brass Liquid Water Flow Sensor For Hot Water Heater

• Description

（50mm）4-branch pipe, 50mm long, G1/2 external teeth for water inlet, internal teeth for water outlet, straight shaped structure, copper waterproof and explosion-proof, heat-resistant and cold resistant, water, tap water standard, long-term use temperature not exceeding 60 ℃, 4-branch copper water flow sensor, water flow sensor for electric faucet, water flow meter for shower room card swiping system, water control machine for measuring water flow sensor, water heater water flow sensor, wall mounted furnace dedicated water flow sensor, can be used as a water flow switch, and can also be used to measure flow and velocity, accurate measurement, three wires: red for positive pole, black for negative pole, yellow for pulse signal, maximum pressure 1.75mpa, flow rate 1-30L/min. If a temperature control sensor is to be added, it is green. Alternatively, two additional wires can be connected specifically to control the temperature. The length of the connecting wires and the type of connecting terminals can be set according to customer requirements. The water flow sensor is mainly used for gas water heaters, electric water heaters, washing machines, water vending machines, wall mounted boilers, electromagnetic water heaters, water control (integrated) machines, water control machines, heat pump hot water engineering, one card management systems, intelligent water meter IC water meters, campus card water sales systems, self-service water vending machines, water treatment equipment, water distribution and dispensing equipment, cooling systems, circulation systems, intelligent mechanical equipment, heating equipment, instruments and meters, pharmaceutical (manufacturing) equipment, etc.
