IP67 Waterproof Stainless Steel With temperature control hole Thermal Sensor Probe NTC Water Temperature Sensors
from
$4.20
Ex Tax: $4.20
- Stock: In Stock
- Model: SCJ2470116J
- Dimensions: 10.00cm x 10.00cm x 5.00cm
- SKU: SCJ2470116J
Products Sold: 0
Product Views: 64
1. Pulse signal output
2. Waterproof, explosion-proof, cold and heat resistant
3, Can be used as a metering flow'water flow switch
4. Straight inlet and outiet water
5. Simple structure and convenient installation
Ask a Question About This Product
- Technical Parameters
Use
flow detection flow meter
Other attributes
Mounting Type
Any direction
Description
flow rate detection
Model Number
SCJ2470116J
Type
Liquid Flow Sensor
Series
flow sensor
Place of Origin
Guangdong, China
Brand Name
SCJ
Theory
Hall principle
Output
Pulse signal output
Description
flow rate sensor
Using objects
Water, etc
Low temperature version
≤60℃
High temperature version
≤115℃
Optional voltage
3V, 5V, 24V
pulseDuty Ratio
50%
insulation resistance
>100MΩ
electric strength
AC500V,50Hz
Flow range
1-30L/min
pressure resistant performance
≤1.75 Mpa
Packaging and delivery
Selling Units:
Single item
Single package size:
10X10X8 cm
Single gross weight:
0.500 kg
- Description
A straight line structure, made of nylon and fiberglass; With fixed foot holes; Equipped with thyristor fixed positioning, heat sink or thyristor can be added; The additional temperature sensor probe hole is waterproof and explosion-proof, heat-resistant and cold resistant, space saving, practical and economical, stable and reliable. 4-point plastic water flow sensor, used for hot electric water heaters, directly equipped with a heating element water flow sensor, with an exposed water inlet that is economical and practical. It is equipped with a Hall water flow switch, pulse signal output, Hall principle, and can be used as a water flow switch, with water and electricity connected, water and electricity disconnected; It can also be used to measure flow rate and achieve constant temperature effect of water heating with controllable silicon. The length of the connecting wire and the type of connecting terminal can be set according to customer requirements. The Hall water flow sensor is mainly used for gas water heaters, electric water heaters, electric faucets, instant hand sanitizers, kitchenware, washing machines, water vending machines, wall mounted boilers, electromagnetic water heaters, water control (integrated) machines, water control machines, water meters, water heating, electric heating, heat pump hot water engineering, one card management system, intelligent water meter IC water meter, campus card water sales system, self-service water vending machine, water treatment equipment, water distribution and dispensing equipment, cooling systems, circulation systems, intelligent mechanical equipment, heating equipment, instruments and meters, pharmaceutical (manufacturing) equipment, etc.
