SC100X25 SC100X50 SC100X100 SC100X150 SC100X200 SC100X250 SC100X300 double Acting Standard Pneumatic Air Cylinder
from
$15.00
Ex Tax: $15.00
5 or more $12.00
10 or more $10.00
100 or more $6.00
- Stock: In Stock
- Model: SCJ007038
- SKU: SCJ007038
Products Sold: 0
Product Views: 142
Ask a Question About This Product
- Description
Product Description
Model | 32 | 40 | 50 | 63 | 80 | 100 | 125 | 160 | 200 |
Motion Pattern | Double Action air cylinder | ||||||||
Working Medium | Air | ||||||||
Fixed Type | Basic type FA type FB type CA type CB type LB type TC type TC-M type | ||||||||
Operating Voltage Range | 1.0~9.0 Kgf/cm² | ||||||||
Ensured Pressure Resistance | 13.5 Kgf/cm² | ||||||||
Operating Temperature Range | 0~70degree | ||||||||
Operating Speed Range | 30~800 mm/s | ||||||||
Buffer Type | Adjustable Buffer | ||||||||
Buffer Stroke | 24 | 32 | |||||||
SC |
50x32 |
N |
S |
FA |
Model SC:Standard Double Acting(Pull Rod Type) SCD:Double-shaft Double Action(Pull Rod Type)) SCJ:Double Axis Double Acting
Adjustable Type(Pull Rod Type) SU:Standard Double Acting(Hidden Pull Rod Type) |
Cylinder Bore X Stroke |
Adjustable stroke: Blank:No magnet N:with magnet 10:10mm 20mm/30mm 40mm/50mm 75mm/100mm |
Magnet Code S:With Magnet Blank:Without Magnet |
Fixed Type Blank:Basic type LB:Front and Back Fixed Type FA:Front Cover Fixed Type(Front Flange Type) FB:Back Cover Fixed
Type(Rear Flange Type) CA:Back Cover Fixed Type(Single Earring) CB:Back Cover Fixed Type(Double Earring) TC:Swinging Type TC-M:Swinging Type Attaching Foot Seat |
