Press Machine Professional Auto Power Sheet CNC Double Crank Punch Press Metal Pneumatic Punching Machines
from
$89,820.00
Ex Tax: $89,820.00
3 or more $89,010.00
10 or more $88,200.00
- Stock: In Stock
- Model: SCJ006628
- SKU: SCJ006628
Products Sold: 0
Product Views: 134
Ask a Question About This Product
- Description
Product Description
Professional stamping automation equipment
The machine body is welded of quality and treated by tension elimination, improve stability and reliability of precision of the machine.
Crank, gear, connect bar are oxidized hardening and milled, having super comrehensive mechanical perfor-mance and durable function.
Reasonable structural design, is convenient for au-tomatic production and line production.
Used reliable high intensity clutch/brake and twin electromagnetic valve, overloading protector can guar-antee safe production all-around.
Adopt safety double solenoid valve and hydraulic overload protection device to ensure production and operation safety.
The mold bearing large impact loading as well as pressing of eccentric mold.
Adopted closed electric loop circuit, have compatible with any automatic equipments.
Main Parameter
Specification | Unit | SYC-110 | SYC-160 | SYC-200 | SYC-250 | ||||
Model | V | H | V | H | V | H | V | H | |
Capacity | Ton | 110 | 160 | 200 | 250 | ||||
Rate tonnage point | mm | 5 | 3 | 6 | 3 | 6 | 3 | 7 | 3.5 |
Stroke | mm | 180 | 110 | 200 | 130 | 250 | 150 | 280 | 170 |
Stroker per Minute | s.p.m | 35-65 | 50-100 | 30-55 | 40-85 | 25-45 | 35-70 | 20-35 | 30-60 |
Die height | mm | 400 | 435 | 450 | 485 | 500 | 550 | 550 | 605 |
Slide adjustment | mm | 100 | 100 | 120 | 120 | ||||
Slide area | mm | 1400ｘ500ｘ70 | 1600ｘ550ｘ70 | 1850ｘ650ｘ95 | 2100ｘ700ｘ95 | ||||
Bolster area | mm | 1800ｘ650ｘ130 | 2000ｘ760ｘ150 | 2400ｘ840ｘ170 | 2700ｘ900ｘ170 | ||||
Main motor | kw.p | 11ｘ4 | 15ｘ4 | 18.5ｘ4 | 22ｘ4 | ||||
Air pressure |
kg/cm2 | 6 | |||||||
Presses precision | GB/JIS 1 class | ||||||||
Presses dimension | mm | 1745ｘ2000ｘ3059 | 1940ｘ2200ｘ3709 | 2235ｘ2620ｘ3849 | 2545ｘ3000ｘ4304 | ||||
More Details
Mould
Type: Stamping press moulds (customized)
Mould Life: 30,000,000 shots,etc. (except wearing part )
Delivery time: 3 to 6 weeks
(3 weeks for prototype mold)
Sample
