Stainless Steel Liquid Float Switch Water Pump tank Level for Boiler Pressure tank Float Level Controller Switch 2m 3m 15m

‌316 Stainless Steel Construction
‌Adjustable Measurement Ranges (2m/3m/15m)
‌Horizontal/Vertical Mounting Compatibility
Magnetic Coupling Switch Mechanism
Explosion-Proof Certification

Buy Now

Technical Parameters

Accuracy

±20mm

Other attributes

place of origin

China

material

stainless steel

warranty

1 year

customized support

Yes

brand name

SCJ

model number

float level switches

measured medium

Tank water, Petrochemical,sewage, oil and other liquids

Protection Grade

IP65

Installation method

horizontal / vertical

Connection

1-1/2 "PT thread or flange

Name

float level switches

Output signal

SPDT NO/NC

Temperature

-20~200°C

Applicable gravity

>=0.55g/cm3

Contact capacity

50W

Pressure range

1.0~3.0MPa

Packaging and delivery

Selling Units:

Single item

Single package size:

15X15X10 cm

Single gross weight:

0.500 kg

Description

This stainless steel float level switch is engineered for precise liquid level control in boilers, pressure tanks, and water pump systems. Its robust 316 stainless steel housing and magnetic float mechanism deliver long-term reliability in corrosive or high-temperature settings ‌. The switch supports adjustable measurement ranges (2m–15m) with ±20mm accuracy, making it ideal for industrial and commercial applications requiring customizable threshold-based pump automation. Explosion-proof certification and threaded mounting options ensure compliance with safety standards and effortless integration into existing setups .
