Cockpit / Cabin Light' Blue LED Latching 19mm Vandal Push Button Switch SPDT 12V

Cockpit / Cabin Light' Blue LED Latching 19mm Vandal Push Button Switch SPDT 12V
Cockpit / Cabin Light' Blue LED Latching 19mm Vandal Push Button Switch SPDT 12V
from
$12.93
Ex Tax: $12.93
5 or more $11.51
10 or more $10.74
25 or more $10.09
50 or more $9.57
  • Stock: In Stock
  • Model: SCJ011129
  • SKU: SCJ011129
Products Sold: 0
Product Views: 37
  • Specifications
Attributes List
ActuationLatching
Contact ConfigurationSPDT
Contact Rating3A 250VAC
Current Rating3A
IlluminatedYes
Electrical Life30,000 Cycles
Illumination ColourBlue
Illumination Voltage12VDC
MaterialStainless Steel
Mounting StylePanel
Number of Poles1
Number of Positions2
Protection LevelIP65
Operating Force5N
Operating Temperature-20°C to +55°C
Panel Cut Out19mm
Panel Thickness1-10mm
Switch OperationOn-On
  • Description
Latching vandal resistant push button switch featuring a blue LED requiring 12V supply voltage and 19mm panel cut-out diameter. The switch housing is stainless steel giving it a long lifespan and resistance against rust. The switch features IP65 protection rating and is suitable for a range of 12V applications including automotive and marine.

  • Suitable for use with adhesive labels
  • Latching action
  • Blue 12V LED
  • Panel cut-out: 19mm
  • Panel thickness: 1-10mm
  • Current rating: 3A
  • Protection level: IP65
  • Contacts: NO/NC
  • Material: stainless steel
  • Terminals: 2.8 x 0.5mm
  • Dimensions: 37 x 22mm (height x diameter)
  • Cockpit / Cabin Light' Blue LED Latching 19mm Vandal Push Button Switch SPDT 12V
