74 Drilling Power Head Column Automatic Vertical Drilling Tapping Machine Spindle Unit

Buy Now

Specifications

Industry-specific attributes
Type	Drilling Head Units
Max. Drilling Dia. (mm)	13
Other attributes
Condition	New
Range of Spindle Speed(r.p.m)	300 - 3000 r.p.m
CNC or Not	Normal
Place of Origin	Zhejiang, China
Weight (KG)	20 KG
Key Selling Points	Automatic
Showroom Location	None
Applicable Industries:	Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company, Other
Marketing Type	Hot Product 2023
Machinery Test Report	Provided
Video outgoing-inspection	Provided
Core Components	Bearing, Pump, Gear, Motor, Gearbox, PLC, Pressure vessel, Engine, Other
Drilling Speed	300-3000r/min
Model Number	D74
Voltage	380v
Dimension(LWH)	650150350mm
Power (kW)	0.75kw
Product name:	D74 Drilling Head Units
Swing	300-3000RPM
Type	Drilling Head Units
Usage	Drilling Metal Parts
Application	Small Hole
Drilling capacity	13mm
Max. drilling diameter	13mm
Material	Steel spindle unit
Color	Customizable
Packaging and delivery
Selling Units:	Single item
Single package size:	70X30X20 cm
Single gross weight:	30.000 kg
Packaging Details	Each drilling head unit is wrapped with stretch film or packed in a wooden case.

Video

Description

Product Description

D74 Pneumatic Power Head Units for Automatic Vertical and Horizontal Drilling Machine

Specification

item	value
Condition	New
Type	Drilling Head Units
Max. Drilling Dia. (mm)	13mm
Range of Spindle Speed(r.p.m)	300r.p.m - 3000r.p.m
CNC or Not	Normal
Drilling Speed	300-3000r/min
Model Number	D74
Voltage	380v
Dimension(LWH)	650150350mm
Power (kW)	0.75w
Weight (KG)	20KG

1. High precision, spindle jitter 0.01mm
2. High speed, the maximum speed of 3000r/min
3. Small size, lightweight, convenient installation
4. The use of 0a .37kw or 0.75kw motor, suitable for small-hole processing

Each drilling head unit is wrapped with stretch film or packed in a wooden case.
